型号 |
MODEL |
Z3050×16 |
|
最大钻孔直径 |
Max. drilling diameter |
50mm |
|
主轴中心线至立柱母线距离 |
Distance between spindle axis and column |
350-1600mm |
|
主轴端面至底座工作面距离 |
Distance spindle nose and working surface of base plate |
32-1220mm |
|
主轴行程 |
Spindle travel |
315mm |
|
主轴锥孔（莫氏） |
Spindle taper |
5# |
|
主轴转速范围 |
Range of spindle speeds |
25-2000r/min |
|
主轴转速级数 |
Number of spindle speeds |
16 steps |
|
主轴进给量范围 |
Range of spindle feeds |
0.04-3.20mm/r |
|
主轴进给量级数 |
Number of spindle feeds |
16 steps |
|
工作台尺寸 |
Table size |
500×630mm |
|
主轴箱水平移动距离 |
Distance of headstock horizontal movement |
1250mm |
|
主电机功率 |
Power of main motor |
4kw |
|
机床外形尺寸（长×宽×高） |
Overall dimensions(L×W×H) |
2500×1070×2840mm |
|
机床重量 |
N.W. |
3500kg |
